NLA exterior door handle A 463 760 0959 for 2002 G500
Topic Tools Message Format
Author
Posted 5/24/2023 5:46 PM
michel bertin
Veteran




Date registered: Jun 2006
Location: SFO Bay Area, CA
Vehicle(s): '02 G500, '14 G550
Posts: 124
100
NLA exterior door handle A 463 760 0959 for 2002 G500

Greetings all,
The push button on the driver’s door handle on my 2002 G500 has been “sticky” and not popping back out any more.
It looks like the mechanism is part of the exterior door handle itself, A 463 760 0959, which shows NLA.

Any idea or have some of you dealt with a similar issue?

I told my tech to try the equivalent part # corresponding to more recent G’s for example from my other 2014 G550 (which ironically also has a similar issue at the left rear door).

Needless to say, we tried the usual spray of lock antifreeze fluid or equivalent, did not solve the issue, only seemed to improve it for a day or so.

Thank you,
Michel
#243937
Top of the page Bottom of the page
Author
Posted 5/27/2023 6:54 AM
Inkblotz
Expert




Date registered: Apr 2006
Location: Georgia
Vehicle(s): 90 300GD "Thundering Turtle II", w/ 603A turbo
Posts: 3186
2000
Re: NLA exterior door handle A 463 760 0959 for 2002 G500

Try this part number: 463-760-01-59

https://parts.mbofcovington.com/oem-parts/mercedes-benz-handle-outsi...

Edited by Inkblotz 5/27/2023 6:55 AM
#243938 - in reply to #243937
Top of the page Bottom of the page
Author
Posted 6/3/2023 7:37 PM
jnicol
Elite Veteran




Date registered: May 2008
Location: Cranbrook, B.C. Canada
Vehicle(s): 91 300GD, 911 (993), Dodge Durango, Subaru rally
Posts: 683
500
Re: NLA exterior door handle A 463 760 0959 for 2002 G500

I also had difficulty finding replacement door handles. Mine is a '91 and so I figured age was the issue. Sorry to hear the newer Gs have the same issue finding parts. I did manage to find 1, but could have used 2.
#243941 - in reply to #243937
Top of the page Bottom of the page
Author
Posted 6/3/2023 7:59 PM
Otiswesty
Administrator




Date registered: Jun 2007
Location: Portland, Oregon
Vehicle(s): 463.241, 461.213
Posts: 3010
2000
RE: NLA exterior door handle A 463 760 0959 for 2002 G500

I ordered a new handle for my 1999 G500 from the local dealer two months ago and got it. Should be the same for any 463 before 2001/2002. For the newer ones, I would recommend using an online dealer like mboemparts.com

1999 G500 locking door handle:
463-760-01-59
Handle, Outside
$96.33
#243942 - in reply to #243937
Top of the page Bottom of the page
Author
Posted 6/9/2023 1:13 PM
michel bertin
Veteran




Date registered: Jun 2006
Location: SFO Bay Area, CA
Vehicle(s): '02 G500, '14 G550
Posts: 124
100
RE: NLA exterior door handle A 463 760 0959 for 2002 G500

Update: my tech dismantled the handle and lock cylinder, found that the culprit was a small O’ring which was worn, replacing it resolved the issue.
They had in parallel ordered the part recommended by Inkblotz, I will keep it as spare.
My 2014 G550 also has a slightly sticky button on one handle, we’ll see.

Michel
#243944 - in reply to #243942
Top of the page Bottom of the page
