| G-AMG G-Class DIY Host Date registered: May 2006 Location: South Texas Vehicle(s): '04 G55, '80 280GE, '99 S420, '98 E320, 2011 E350  | Photo DIY- A/C Condensor Replacement. At first I thought this to be a bit too "esoteric" of a DIY, but after reading several posts, this seems to be a fairly "common" problem. Since I had a micro leak, I was forced to replace mine. Please be environment conscious, and have your system evacuated BEFORE starting this job. PLUS<<< your system will NOT be under HIGH PRESSURE!! The usual CYA blah, blah stuff. I am not claiming any expertise. I make no bones about it, I am a novice mechanic. My projects are based on my interpretation of the WIS procedures, and/or outside sources. Do work at your own discretion. (1.JPG) (2.JPG) (3.JPG) (4.JPG) (5.JPG) (6.JPG) (7.JPG) (8.JPG) (9.JPG) (9a.JPG) (9b.JPG) (9c.JPG) (9d.JPG) (9e.JPG) (9f.JPG) (9g.JPG) (9h.JPG) (9i.JPG) (9J.JPG) (9k.JPG) (9L.JPG) (9m.JPG) (9n.JPG) (9O.JPG) (9p.JPG) (9q.JPG) Attachments ----------------  1.JPG (97KB - 190 downloads) 2.JPG (105KB - 201 downloads) 3.JPG (122KB - 219 downloads) 4.JPG (97KB - 201 downloads) 5.JPG (82KB - 214 downloads) 6.JPG (98KB - 199 downloads) 7.JPG (94KB - 236 downloads) 8.JPG (104KB - 206 downloads) 9.JPG (88KB - 226 downloads) 9a.JPG (83KB - 208 downloads) 9b.JPG (88KB - 231 downloads) 9c.JPG (102KB - 217 downloads) 9d.JPG (109KB - 223 downloads) 9e.JPG (104KB - 204 downloads) 9f.JPG (96KB - 216 downloads) 9g.JPG (129KB - 211 downloads) 9h.JPG (141KB - 211 downloads) 9i.JPG (126KB - 202 downloads) 9J.JPG (69KB - 200 downloads) 9k.JPG (83KB - 182 downloads) 9L.JPG (120KB - 233 downloads) 9m.JPG (141KB - 216 downloads) 9n.JPG (83KB - 224 downloads) 9O.JPG (101KB - 207 downloads) 9p.JPG (89KB - 196 downloads) 9q.JPG (128KB - 204 downloads) | |
| ||
| ||
| G-AMG G-Class DIY Host Date registered: May 2006 Location: South Texas Vehicle(s): '04 G55, '80 280GE, '99 S420, '98 E320, 2011 E350 | RE: Photo DIY- A/C Condensor Replacement. SORRY! I missed one Pic. It should be BEFORE the LOWER HOSE hook-up. (9M1.JPG) Attachments ---------------- 9M1.JPG (114KB - 200 downloads) | |
| ||
|
